Product 1-2
Controller,LCD display,metal keyboard
Auto.shut off nozzle
Motor:AC 110V1220V1380V
Optional parts:stablizer,LED advertisment,emergencystop button,breakaway etc.
Technical parameter |
Ambient temperature | -25°C~ +55°C |
Humidity | ≤90% |
Flow rate | 5~60L/min or 5~90L/min |
nozzle | Auto shut-off |
Suction distance | 6m(Vertical), 50m(horizontal) |
Accuracy | ±0.30% |
Repeating tolerance | ≤0.15% |
Hose | 3m(low hang), 4.5m(high hang) |
Inlet pressure | ≥54kPa |
Outlet pressure | ≤0.3MPa |
Voltage | 12V/24V110V/220V/380V |
Power | 1HP(0.75kw) |
Noise | ≤80dB(A class) |
Unit price range | 0.01~999.99 |
single volume range | 0.01~999999.99 |
accumulative volume range | 0.01~9999999999.99 |
Explosion-proof signal | ExdmbIIAT3 |
