Technical index name | Content of technical indicators
|
Input voltage | AC220V±15% |
Ac Frequency Range | 50/60Hz±10% |
The Output Voltage | AC220V±15% |
Rated output current | 32A |
maximum output power | national standard 7KW | American-Standard 11KW | European standard 22KW |
Insulation Properties | ≥10mΩ(Output integrated shell) |
Working Environment | Elevation≤2000m temperature-30~50°C humidity 95% |
charging method | Automatic charging/appointment charging |
| Protection class | IP55 |
| Security | Over voltage, under voltage, over current, short circuit, output reverse connection, overheating, leakage protection, lightning protection |
| Charging gun life | ≥10000次 Times or more |
| Three defenses | The shell is made of metal material to prevent moisture, salt spray and mildew.Resistant to abnormal heat and fire |
