240KW Double gun charging pile
240KW Double gun charging pile
Technical specification
| Rated Power | 240KW |
| Maximum Output Current | 250A |
| Output Voltage Range | Dc150 - 750V (1000V) Selectable And Adjustable |
| Input Voltage | AC380V± 20%(Three phase+N+PE) |
| Input Frequency | 50HZ± 10%HZ |
| Output Loop | 4 way /6 way /8 way |
| Constant Power Output Voltage Range | DC400 - 750V |
| Efficiency | ≥95% |
| Power Factor | ≥0.99（50%-100% Full load output power） |
| Voltage Regulation Accuracy | ≤± 0.5% |
| Steady Flow Accuracy | ≤± 1%（ 20%-100% Output load 20%-100% quota range） |
| Current Unbalance | ≤± 5% |
| Stable Peak-to-peak | ≤1% |
| Insulation Resistance | ≤20MΩ |
| Protection Class | IP54 |
| Noise | ≤65DB |
| Cooling Method | Forced Air Cooling |
| Operating Temperature | -30°C~+50°C |
| Storage Temperature | -40°C~+70°C |
| Relative Humidity | 5%~95% |
