40KW~200KW Double gun charging pile
40KW~200KW Double gun charging pile
Technical specification
| Rated power | 40KW | 60KW | 80KW | 120KW | 200KW |
| Maximum output current | 50A；180A；250A | ||||
| Constant power output voltage range | DC330v - 750V | ||||
| Nput voltage | AC380V± 20% | ||||
| Input frequency | 50HZ/60HZ± 10%HZ | ||||
| Output voltage range | DC150 - 750V (1000V)Selectable and adjustable | ||||
| Output voltage error | ≤± 0.5% | ||||
| Output current error | ≤± 1% | ||||
| Voltage regulation accuracy | ≤± 0.5% | ||||
| Steady flow accuracy | ≤± 1% | ||||
| Power factor | ≥ 0.99 | ||||
| Efficiency | ≥95% | ||||
| Insulation resistance | ≥ 20MΩ | ||||
| Noise | ≤60dB | ||||
| Protection class | IP54 | ||||
| Operating temperature | - 30°C~+50°C | ||||
| Storage temperature | - 40°C~～+70°C | ||||
| Relative Humidity | 5% ~95% | ||||
