Project name | Parameter range |
Adapt temperature | -40℃～+55℃ |
Relative humidity | ≤95% |
Air pressure | 86～106KPa |
Voltage | AC220V±20% or AC380V±20% |
Frequency | (50±1)HZ√ (60±1)HZ |
Single range | 1～9999.99 ,1～999999.99(changeable) |
Range of cumulative number of classes | 0~99999999 |
Unit price setting range | 0～9999,0～999999(changeable) |
Accumulative range | 0~9999999999.99 |
Solenoid valve turn off setting range | 0~0.99L |
Nozzle No. | From1~10（OEM） |
Pump type | Suction pump/submersible pump |
The Number Of Digits Displayed On The Display
6 digits in volume, 6 digits in amount, and 4 digits in unit price (664)
8 digits in volume, 8 digits in amount, and 6 digits in unit price (886)
Electronic Calibration Feature.
Pump Locking Function.
Fueling Time Limit Function.
Locking Function.
Total Amount Stop Function.
Optional Voice Reporting and Printout Functions.
The decimal point can be set for the display, making it usable in multiple countries with different currency rates.
Offers a choice of 7-digit electromagnetic counter or 9-digit mechanical totalizer counter.
Communication ports are available for connectivity with gas station management systems.
GPRS functionality can be added to connect with a mobile phone for checking data and setting unit prices anytime, anywhere.
Solar power functionality can be added.
Touch Screen Functionality
Handshake functionality can be added.
TV Media Display Option.
OEM customization is available as required.
