TESLA To J1772 Adapter
type：Tesla to SAE J1772 Standard，AC charging adapter
Main Markets：USA ,Canada，Mexico ， Korea ， Taiwan ,Japan
| Color | black | Pins | Copper alloy，silver plated |
| Rated power | 20KW max | service life
| >10000 times |
| Current | 80A max
| Sealing gasket | silicon rubber |
| Operating voltage | 110V-250V AC | Storage temperature | -30°C~50°C |
| Conductor Material | Titaniym copperalloy | Ecurity | locks into the vehicle while charging |
| Shell Material | PC+ABS | Certification | CE、FCC |
| Flame retardant grade | UL94-V0 | Warranty | 12 moths |
| Operating temperature | -40°C~+85°C | connector
| TESLA(AC) |
| Protection class | IP54 | Dual temperature kill switch Stops charging when the adapter reaches 90°C |
J1772 To TESLA Adapter
Type：american standard DC adapter
Main Markets：North America、Mexico、Southeast Asia
| Color | black | Pins | Copper alloy，silver plated |
| Rated power | 20KW max | service life
| >10000 times |
| Current | Up to 80A max
| Sealing gasket | silicon rubber |
| Operating voltage | 110V-250V | Storage temperature | -30°C~50°C |
| Insulation resosotance | >1000mΩ | Housing | Thermoplastic |
| Contact resistance | <5mΩ | Certification
| CE、FCC |
Flame retardant grade
| UL94-V0 | Warranty | 12 months |
| Operating temperature | -40°C~+85°C | connector
| J1772（AC） |
| Protection class | IP54 | Dual temperature kill switch Stops charging when the adapter reaches 90°C |
J1772 To GBT Adapter
type：american standard to GB AC Adapter
Main Markets：Mexico、South America，Africa
| Color | black | Pins | Copper alloy，silver plated |
| Rated power | 8KW max | service life
| >10000 times |
| Current | 32A max
| Plastic | PC+ABS |
| Operating voltage | 110-250V | Storage temperature | -30°C~50°C |
| Insulation resosotance | >1000mΩ | Unique design | with switch |
| Contact resistance | <5mΩ | Certification
| FCC |
Flame retardant grade
| UL94-V0 | Warranty | 12 months |
| Operating temperature | -40°C~+85°C | connector
| J1772（AC） |
| Protection class | IP54 | Dual temperature kill switch Stops charging when the adapter reaches 90°C |
