WDYB Series With Coupling Connect

点击发送询问
相关产品推荐

参数说明

WDYB Series Rotary Vane Pump

Advantages:

  1. Fast and Quiet Long-Term Operation: The WDYB Series Rotary Vane Pump boasts a high-efficiency design that ensures rapid and low-noise operation over extended periods, providing a peaceful and efficient working environment.

  2. Stable Sliding Vane Design with High Reliability: Equipped with an advanced sliding vane technology, this pump exhibits exceptional stability and reliability during operation, minimizing the risk of failures, reducing maintenance costs, and extending equipment lifespan.

  3. Adjustable Relief Valve to Prevent Excessive Pressure: Featuring an adjustable relief valve, the pump can be customized to protect against excessive pressure, ensuring safe and stable operation over time.

Application:

  • Oil Tank Trucks: Suitable for transporting fuel or lubricant oil in various oil tank trucks, ensuring stable and efficient medium transfer during transportation.

  • Fleet Refueling: Provides rapid and accurate refueling services for large fleets, meeting the fuel replenishment needs of ships during navigation.

  • Lubricating Oil: Widely used in industrial lubricant transmission systems, ensuring timely and sufficient lubrication for equipment, thereby extending their service life.

  • Aviation Refueling: Specifically designed for the aviation industry, it meets the high-precision and safety requirements of aviation fuel transmission, supporting the safe flight of aircraft.

  • Petrochemicals, Gasoline, Diesel, Biofuels, Solvents, and More: Covers a broad range of petrochemical product transmission, including gasoline, diesel, biofuels, solvents, and various other media, catering to the diverse fluid transmission needs of various industries.

The WDYB Series Rotary Vane Pump, with its outstanding performance and versatility, has become the ideal choice for fluid transmission in numerous industries.

 Construction:






Technical Specification

型号

Model

WDYB-50

WDYB-65

WDYB-80

WDYB-100

不带电机Without motor

带皮带轮驱动电机

With motor V-Belt driven

不带电机Without motor

带皮带轮驱动电机

With motor V-Belt driven

不带电机Without motor

带皮带轮驱动电机

With motor V-Belt driven

不带电机Without motor

口径

Size

50mm/2”

65mm/

80mm/3”

100mm/4”

泵转速

Pump speed

400-640RPM

400-640RPM

400-640RPM

500RPM

最大流量

Max Flow rate

150-300L/min

300-500L/min

600-1000L/min

1500-1900L/min

真空度

Vacuum

0.5Bar

 工作压力

Working pressure

5Bar

电机功率

Motor power

2.2KW

4KW

7.5KW

18.5KW

包装尺寸

Dimension

44X35X35

cm

76X51X55

cm

46X34X37

cm

76X54X56

cm

49X42X42

cm

125X46X79

cm

58X55X61cm

净重

Net weight

31KG

86KG

40KG

126KG

68KG

238KG

160KG

毛重

Gross weight

34KG

118KG

47G

146KG

74KG

266KG

178KG

包装

Package

1台/木箱  1pc/wooden case
