WD-SUB Vane Pump

WD-SUB

点击发送询问
WD-SUB Vane Pump
相关产品推荐

参数说明





WD-SUB Series Vane Pump is positive displacement vane pump, applied to transfer gasoline, kerosene, diesel and other light oil, used to load & unload in stock terminal, also on oil tank trucks and mobile fuel unit.



Technical Data:



Model

WD-SUB-40

WD-SUB-50

WD-SUB-80

Inlet & Outlet Size

40mm

50mm

80mm

Flow Rate

180L/min

250L/min

550L/min

Vacuum

0.06MPa

0.06MPa

0.06MPa

Speed

960RPM

960RM

960RPM

Kw

1.5KW

1.5KW





Application:

Fuel Oil Delivery Truck

Fleet Refuelers

Aviation Refuelers

Loading & Unloading in Stock Terminal

Transport of Petrol, Gasoline, Diesel, Kerosene and Many More



Advantage:

An excellent self-priming performance, vacuum up 0.095MPa,intstead of vacuum pump to clean the tank in vessel, truck, etc.

To transport gas-liquid two-phase, up to 50%,completely solve air lock, cavitation.

Sliding vane design provides sustained performance and trouble free operation, high reliability

Adjustable relief valve protects pump from excessive pressure.
